| 规格mm | 相对测量面平行度 | 相邻两侧面垂直度 | 测量面直线度 | ||||||
| 精度等级um | |||||||||
| 0 | 1 | 2 | 0 | 1 | 2 | 0 | 1 | 2 | |
| 200×200×30 | 4 | 8 | 16 | 1.5 | 3 | 6 | 4 | 8 | 16 |
| 250×250×30 | 4.5 | 9 | 18 | 2 | 8 | 8 | 4.5 | 9 | 18 |
| 300×300×30 | 5 | 10 | 20 | 2.3 | 9 | 9 | 5 | 10 | 20 |
| 400×400×40 | 6 | 12 | 24 | 2.6 | 10 | 10 | 6 | 12 | 24 |
| 500×500×50 | 7 | 14 | 28 | 3 | 12 | 12 | 7 | 14 | 28 |
| 600×600×50 | 8 | 16 | 32 | 3.5 | 14 | 14 | 8 | 16 | 32 |
